Isolation using TeleLite Fiber Optic System
High voltage isolation using optical fiber which isolates two points in a copper loop (Hybrid solution). Fiber optic isolation solutions are available in a variety of suitable metallic (NEBS Level 3) and non-metallic NEMA 4X rated polymer cabinets.
The Positron TeleLite system provides electrical isolation between two enclosures on a telecom landline separated by a fiber optic link. This provides very high electrical isolation between the Central Office (CO) and Customer Premise Equipment (CPE), or Station Side. The data and voice on the copper line is converted to optical signals and then reconverted to data and voice copper line at the station side. TeleLite installations are deployed at Power Generation Plants, Power Substations, and on Power Transmission Towers when Telecommunications lines are colocated.
The station side can be located indoors or outdoors. The CO side, located at a distance away from the station side, lies where the GPR is below 300V with respect to the CO.
TeleLite Product Line
- TeleLite fiber modules isolator breaks the copper continuity of the telephone line by inserting a length of all-dielectric, optical fiber between the Central Office (CO) and the substation over the Zone of Influence (ZOI)
- TeleLite is FCC registered for Part 68 and Part 15, subpart J (required for CPE connection to the PSTN)
- Basic building blocks for a TeleLite installation include:
- Pre-configured HVI units (Cabinets and Backboards)
- Compact HVI (1U 2-slot shelf, 3-card enclosures)
- 6-position shelf
- Fiber optic modules on plug-in PCBs
- The TeleLite fiber isolators are modular, permitting selection of the specific cards needed for different applications
- Both single mode (SM) and multimode (MM) fiber are readily accommodated by selecting compatible TeleLite isolation cards and fiber optic jumpers
- TeleLite is NEBS Level 3 compliant
Positron will be pleased to assist you in your system designs and help you choose the right modules for your installations.
TeleLite Plug-in Cards
| PRODUCT NUMBER | DESCRIPTION | PRODUCT PICTURE | TECH SPECS / MANUALS |
|---|---|---|---|
| Multi-card Shelves | |||
| 720000 | TeleLite 6-slot Shelf |  | DOWNLOAD |
| 720002 | TeleLite 2-slot Shelf |  | DOWNLOAD |
| 720013 | TeleLite 3-slot Swing-out Shelf |  | DOWNLOAD |
| Plug-In Power Supply Cards | |||
| 720001 | Access Card Direct -48 Vdc |  | DOWNLOAD |
| 721123 | Power Access Card (50 Watts) Input 120 Vac / 130 Vdc to -48 Vdc Output |  | DOWNLOAD |
| 721124 | Power Access Card (15 Watts) Input 130 Vdc to -48 Vdc Output |  | DOWNLOAD |
| 721125 | Power Access Card (15 Watts) Input floating 48 Vdc Output |  | DOWNLOAD |
| Line Powered Enhanced T1 | |||
| 720100MST | Single Enhanced T1 Station Multi-Mode ST Conn-Local Powered |  | DOWNLOAD |
| 720100SSC | Single Enhanced T1 Station Single-Mode ST Conn-Local Powered | ||
| 720110MST | Single Enhanced T1 Station Office Multi-Mode ST Conn-Local Powered | ||
| 720110SSC | Single Enhanced T1 Station Office Single-Mode ST Conn-Local Powered | ||
| 720120MST | Dual Enhanced T1 Station Multi-Mode ST Conn-Local Powered |  | |
| 720120SSC | Dual Enhanced T1 Station Single-Mode ST Conn-Local Powered | ||
| 720130MST | Dual Enhanced T1 Station Office Multi-Mode ST Conn-Local Powered | ||
| 720130SSC | Dual Enhanced T1 Station Office Single-Mode ST Conn-Local Powered | ||
| Quad Ethernet 10/100 Mbps | |||
| 720930MST | Ethernet Unmanaged Switch POE Multi-Mode ST Conn |  | DOWNLOAD |
| 720930SSC | Ethernet Unmanaged Switch POE Single-Mode SC Conn | ||
| 720920MST | Ethernet Unmanaged Switch PSE Multi-Mode ST Conn | ||
| 720920SSC | Ethernet Unmanaged Switch PSE Single-Mode SC Conn | ||
| Local Powered Data 56k DDS | |||
| 720300MST | Data 56k DDS Station Multi-Mode ST Conn- Local Powered |  | DOWNLOAD |
| 720300SSC | Data 56k DDS Station Single-Mode SC Conn- Local Powered | ||
| 720310MST | Data 56k DDS Station Multi-Mode ST Conn- Local Powered | ||
| 720310SSC | Data 56k DDS Station Single-Mode SC Conn- Local Powered | ||
| Line Powered Data 56k DDS | |||
| 720360MST | Data 56k DDS Station Multi-Mode ST Conn- Local Powered |  | DOWNLOAD |
| 720360SSC | Data 56k DDS Station Single-Mode SC Conn- Local Powered | ||
| 720370MST | Data 56k DDS Station Multi-Mode ST Conn- Local Powered | ||
| 720370SSC | Data 56k DDS Station Single-Mode SC Conn- Local Powered | ||
| PRODUCT NUMBER | DESCRIPTION | PRODUCT PICTURE | TECH SPECS / MANUALS |
|---|---|---|---|
| Line Powered POTS | |||
| 720260MST | Single POTS FX Station Multi-Mode ST Conn Local Powered |  | DOWNLOAD |
| 720260SSC | Single POTS FX Station Single-Mode SC Conn Local Powered | ||
| 720270MST | Single POTS FX Station Office Multi-Mode ST Conn Local Powered | ||
| 720270MST | Single POTS FX Station Office Single-Mode SC Conn Local Powered | ||
| Local Powered POTS with Caller ID | |||
| 720640MST | Dual POTS Featured CLID, Ground Start, Loop Start Foreign Exchange Station Multi-Mode ST Conn Local Powered |  | DOWNLOAD |
| 720640SSC | Dual POTS Featured CLID, Ground Start, Loop Start Foreign Exchange Station Single-Mode SC Conn Local Powered | ||
| 720650MST | Dual POTS Featured CLID, Ground Start, Loop Start Foreign Exchange Station Office Multi-Mode ST Conn Local Powered | ||
| 720650SSC | Dual POTS Featured CLID, Ground Start, Loop Start Foreign Exchange Station Office Single-Mode SC Conn Local Powered | ||
| 720600MST | Quad POTS Featured CLID, Ground Start, Loop Start Foreign Exchange Station Multi-Mode ST Conn Local Powered |  | |
| 720600SSC | Quad POTS Featured CLID, Ground Start, Loop Start Foreign Exchange Station Single-Mode SC Conn Local Powered | ||
| 720610MST | Quad POTS Featured CLID, Loop Start Foreign Exchange CO Multi-Mode ST Conn Local Powered | ||
| 720610SSC | Quad POTS Featured CLID, Loop Start Foreign Exchange Station CO Single-Mode SC Conn Local Powered | ||
| Line Powered POTS 2-Wire/ 4-Wire AC DATA | |||
| 720460MST | 2W/4W Station -48V Multi-Mode ST Conn Local Powered | | DOWNLOAD |
| 720460SSC | 2W/4W Station -48V Single-Mode ST Conn Local Powered | ||
| 720470MST | 2W/4W Central Office -48V Multi-Mode ST Conn Local Powered (If loop current is available) | ||
| 720470SSC | 2W/4W Central Office -48V Single-Mode ST Conn Local Powered (If loop current is available) | ||
| Local Powered POTS 4-Wire AC DATA | |||
| 720480MST | Dual 4-Wire AC DATA Station -48V Multi-Mode ST Conn Local Powered |  | DOWNLOAD |
| 720480SSC | Dual 4-Wire AC DATA Station -48V Single-Mode SC Conn Local Powered | ||
| 720490MST | Dual 4-Wire AC DATA Central Office -48V Multi-Mode ST Conn Local Powered | ||
| 720490SSC | Dual 4-Wire AC DATA Central Office -48V Single-Mode SC Conn Local Powered | ||
| Local Powered DID | |||
| 720740MST | Dual DID FXO Station Multi-Mode ST Conn Local Powered |  | DOWNLOAD |
| 720740SSC | Dual DID FXO Station Single-Mode ST Conn Local Powered | ||
| 720750MST | Dual DID FXS Central Office Multi-Mode ST Conn Local Powered | ||
| 720750SSC | Dual DID FXS Central Office Single-Mode ST Conn Local Powered | ||
| 720700MST | Quad OPX FXO Station Multi-Mode ST Conn Local Powered |  | |
| 720700SSC | Quad OPX FXO Station Single-Mode ST Conn Local Powered | ||
| 720710MST | Quad OPX FXO Central Office Multi-Mode ST Conn Local Powered | ||
| 720710SSC | Quad OPX FXO Central Office Single-Mode ST Conn Local Powered | ||
| Local Powered OPX | |||
| 720840MST | Dual OPX FXO Station Multi-Mode ST Conn Local Powered |  | DOWNLOAD |
| 720840SSC | Dual OPX FXO Station Single-Mode ST Conn Local Powered | ||
| 720850MST | Dual OPX FXO Central Office Multi-Mode ST Conn Local Powered | ||
| 720850SSC | Dual OPX FXO Central Office Single-Mode SC Conn Local Powered | ||
| 720800MST | Quad OPX FXO Station Multi-Mode ST Conn Local Powered |  | |
| 720800SSC | Quad OPX FXO Station Single-Mode SC Conn Local Powered | ||
| 720810MST | Quad OPX FXO Central Office Multi-Mode ST Conn Local Powered | ||
| 720810SSC | Quad OPX FXO Central Office Single-Mode SC Conn Local Powered | ||
TeleLite HVI Configurations (Cabinets & Backboards)
| PRODUCT NUMBER | DESCRIPTION | PRODUCT PICTURE | TECH SPECS / MANUALS |
|---|---|---|---|
| TeleLite HVI Cabinet Enclosures | |||
| 7243NC-WL | 40" x 30" NEBS Cabinet Enclosure- Wall-Mount |  | DOWNLOAD |
| 7243NC-PL | 40" x 30" NEBS Cabinet Enclosure- Pole-Mount | ||
| 7243NC-PD | 40" x 30" NEBS Cabinet Enclosure- Pad-Mount | ||
| 7232PC-WL | 30" x 20" Polymer Cabinet Enclosure- Wall-Mount |  | |
| 7232PC-PL | 30" x 20" Polymer Cabinet Enclosure- Pole-Mount | ||
| 7243PC-WL | 40" x 30" Polymer Cabinet Enclosure- Wall-Mount |  | |
| 7243PC-PL | 40" x 30" Polymer Cabinet Enclosure- Pole-Mount | ||
| TeleLite HVI Backboard CFJ/OEI | |||
| 7243BS-10 | 35" x 27" TeleLite Backboard w/ one (1) 6-slot Shelf, 25-pair Protected Punch Block with 66-block X-connect |  | DOWNLOAD |
| 7243BD-10 | 35" x 27" TeleLite Backboard w/ two (2) 6-slot Shelves, 25-pair Protected Punch Block with 66-block X-connect |  | |
| 7243BD-22 | 35" x 27" TeleLite Backboard w/ two (2) 6-slot Shelves, 3M Protection and two (2) DTWA (NEBS) |  | |
| 7232BS-10 | 25" x 15" TeleLite Backboard w/ one (1) 6-slot Shelf, 25-pair Protected Punch Block with 66-block X-connect |  | |
| Complete TeleLite HVI Assemblies - ZOI CFJ Assembly | |||
| 724200/05 | 37" x 29" TeleLite ZOI CFJ Red Backboard Assembly w/ one (1) 6-slot Shelf, ADC Jacks with 66-block X-connect |  | DOWNLOAD |
| 724200/15 | 40" x 32" TeleLite ZOI CFJ Polymer Cabinet Assembly w/ Red Backboard, one (1) 6-slot Shelf, ADC Jacks, 66-block X-connect |  | |
| 724220/05 | 37" x 29" TeleLite ZOI CFJ Polymer Cabinet Assembly w/ Red Backboard, two (2) 6-slot Shelves, ADC Jacks, 66-block X-connect |  | |
| 724220/15 | 40" x 32" TeleLite ZOI CFJ Polymer Cabinet Assembly w/ Red Backboard, two (2) 6-slot Shelves, ADC Jacks, 66-block X-connect |  | |
| Complete TeleLite HVI Assemblies - CFJ & OEI Assembly | |||
| 724201/05 | 27" x 21" TeleLite CFJ / OEI Backboard Assembly (white) with one (1) 6-slot Shelf, 25-pair Protected Punch Block, 66 Punch Block X-connect |  | DOWNLOAD |
| 724201/15 | 32" x 24" TeleLite CFJ / OEI Polymer cabinet Assembly w/ one (1) 6-slot Shelf, 25-pair Protected Punch Block, 66 Punch Block X-connect |  | |
| 724211/05 | 37" x 29" TeleLite CFJ / OEI Backboard Assembly (white) with one (1) 6-slot Shelf, 25-pair Protected Punch Block, 66 Punch Block X-connect |  | |
| 724211/15 | 40" x 32" TeleLite CFJ / OEI Polymer Cabinet Assembly w/ one (1) 6-slot Shelf, 25-pair Protected Punch Block, 66 Punch Block X-connect |  | |
| 724221/05 | 37" x 29" TeleLite CFJ / OEI Backboard Assembly (white) with two (2) 6-slot Shelves, 25-pair Protected Punch Block, 66 Punch Block X-connect |  | |
| 724221/15 | 40" x 32" TeleLite CFJ / OEI Polymer Cabinet Assembly w/ two (2) 6-slot Shelf, 25-pair Protected Punch Block, 66 Punch Block X-connect |  | |
| cHVI | |||
| 7222PS-PL | cHVI 3-slot TeleLite Shelf, Polymer Cabinet Pole-Mount |  | N/A |
| 7222PS-WL | cHVI 3-slot TeleLite Shelf, Polymer Cabinet Wall-Mount | ||
TeleLite Accessories
| PRODUCT NUMBER | DESCRIPTION | PRODUCT PICTURE | TECH SPECS / MANUALS |
|---|---|---|---|
| TeleLite Accessories | |||
| 7220PE-PG | Pedestal (Dim: 14" x 20" x 42") |  | DOWNLOAD |
| 7220PE-10 | Pedestal (Dim: 14" x 20" x 42") w/ 3/4" Treated Plywood Backboard, Incl. One (1) 3-slot Shelf (720013) and Fiber Routing Guide |  | |
| 7220PE-20 | Pedestal (Dim: 14" x 20" x 42") w/ 3/4" Treated Plywood Backboard, Incl. Two (2) 3-slot Shelf (720013) and Fiber Routing Guide |  | |
| 719996 | 23" Rack-Mount Bracket Kit for Shelf |  | N/A |
| 719999 | Blank face Plate |  | N/A |
| 750001 | Dielectric Pad (Dim: 4" x 30" x 48") |  | N/A |
| 72505P-12 | 5 Pin Protectors (Qty 12) |  | N/A |
| 7200DT-04 | 4-Position Digital Termination Assembly |  | N/A |
